PACIFIC 550A Dicer


The Pacific 550A is a high speed dicing machine that is suitable for butcher shops, meat processors, delis, supermarkets, and fruit & vegetable processors. The cutting blades on the machine can be adjusted in 5mm increments to suit your dicing size requirements, maximum cutting dimensions of 120x120x550mm, an out feed conveyor will move your diced product to a height suitable for dumping into a standard 200L euro bin, it is quick and easy to load product into the machine whilst also maintaining the highest levels of operator safety and manufactured from 304 stainless steel. This machine is suitable for: fresh meat, semi frozen meat, back fat, bacon & ham, cooked & cured sausages, softer vegetables such as potato & carrot, fruit & some cheeses.

Suitable for: Fresh meat (boneless), semi-frozen meat (boneless), back fat, bacon, ham, cooked or cured sausage, softer vegetables (such as potatoes and carrots), fruits & some cheeses.

Model Pacific 550A
Capacity up to 800-1000kg
Dicer chamber size 120 x 120 x 550 mm
Cutting grid sizes 5/10/15/30 mm (5mm increments)
Dice cut length 3 - 30mm
Product processing temperature -4c to 30c (optimal cutting temperature is as close to -4c as possible)
Voltage 380V 50Hz, 3 Phase
Total power 3.95kW
Main shaft motor power 2.2kW
Oil pump motor power 1.5Kw
Conveyor motor 0.25kW
Weight 730kg
Overall dimensions 1812 x 1387 x 1280 mm
