Revic 2000L Jacketed Boiling Kettle with Hydraulic Basket

CONDITION:
NEW
STOCK STATUS:
ENQUIRE

Heat boilers made by Revic are designed to for the cooking and blanching of sausages, hams, offal and many other products. Made entirely of stainless steel AISI304 with a tightly sealed lid, the with electric heating. The kettles are made to operate in automatic mode by using proven and reliable micro-controller to control the technological process. Designed with durability in mind, providing the highest quality of processed batches, with minimal engagement of handling.

  • Made in Poland
  • Constructed out of stainless steel AISI 304
  • All elements (hydraulic agegate, hydraulic arms, electrical system) hidden in housing
  • System ensures the correct sequence of actuators action (first lid, then basket, etc.)
  • System prevents free falling in the event of lack of pressure
  • Smooth basket unload (with adjustable speed of basket tilt)
  • Double heat jacket – oil shell
Tank Capacity 2000L
Tank Dimensions 3300 x 1020 x 625 mm
Hole Diameter (Basket) 15mm, arranged 50x50mm (other dimensions/arrangements available)
Voltage 400V 50Hz, 3 Phase
Heating Power 65kW
Hydraulic Power 1.5kW
Hydraulic Arm Capacity 2x 2100 kg
Angle of Lid Opening 95°
Angle of Basket Tilt 120°
Water Connection 3/4"
Water Drain 2"
Weight ~1200kg
Overall Dimensions 3900 x 1350 x 1200 mm
