Revic 2000L Jacketed Boiling Kettle with Hydraulic Basket


Heat boilers made by Revic are designed to for the cooking and blanching of sausages, hams, offal and many other products. Made entirely of stainless steel AISI304 with a tightly sealed lid, the with electric heating. The kettles are made to operate in automatic mode by using proven and reliable micro-controller to control the technological process. Designed with durability in mind, providing the highest quality of processed batches, with minimal engagement of handling.

  • Made in Poland
  • Constructed out of stainless steel AISI 304
  • All elements (hydraulic agegate, hydraulic arms, electrical system) hidden in housing
  • System ensures the correct sequence of actuators action (first lid, then basket, etc.)
  • System prevents free falling in the event of lack of pressure
  • Smooth basket unload (with adjustable speed of basket tilt)
  • Double heat jacket – oil shell
Tank Capacity 2000L
Tank Dimensions 3300 x 1020 x 625 mm
Hole Diameter (Basket) 15mm, arranged 50x50mm (other dimensions/arrangements available)
Voltage 400V 50Hz, 3 Phase
Heating Power 65kW
Hydraulic Power 1.5kW
Hydraulic Arm Capacity 2x 2100 kg
Angle of Lid Opening 95°
Angle of Basket Tilt 120°
Water Connection 3/4"
Water Drain 2"
Weight ~1200kg
Overall Dimensions 3900 x 1350 x 1200 mm
